DATA : N1 TYPE i.
DATA : N2 TYPE i.
DATA : N3 TYPE i.
DATA : res TYPE i.
DATA : ok_code TYPE sy-ucomm.
MODULE status_9000 OUTPUT.
* SET PF-STATUS ‘xxxxxxxx’.
* SET TITLEBAR ‘xxx’.
ENDMODULE. ” STATUS_9000 OUTPUT
MODULE user_command_9000 INPUT.
CASE ok_code.
WHEN ‘ADD’.
CALL SCREEN 9001.
ENDCASE.
ENDMODULE. ” USER_COMMAND_9000 INPUT
MODULE status_9001 OUTPUT.
* SET PF-STATUS ‘xxxxxxxx’.
* SET TITLEBAR ‘xxx’.
res = N1 + N2 + N3.
ENDMODULE. ” STATUS_9001 OUTPUT
MODULE user_command_9001 INPUT.
CASE ok_code.
WHEN ‘BACK’.
CALL SCREEN 9000.
ENDCASE.
ENDMODULE. ” USER_COMMAND_9001 INPUT
module CHECK_TWO_NUMBER input.
N1 = N1 + 10.
N2 = N2 + 10.
endmodule. ” CKECK_THREE_NUMBER INPUT
FLOW LOGIC OF SCREEN 9000
PROCESS BEFORE OUTPUT.
MODULE status_9000.
PROCESS AFTER INPUT.
CHAIN.
FIELD : N1,N2.
MODULE CHECK_TWO_NUMBER ON CHAIN-INPUT.
ENDCHAIN.
MODULE user_command_9000.
FLOW LOGIC OF SCREEN 9001
PROCESS BEFORE OUTPUT.
MODULE STATUS_9001.
PROCESS AFTER INPUT.
MODULE USER_COMMAND_9001.
Run the program and if you provide any value to either n1 or n2 or both then only CHECK_TWO_NUMBER module will execute . press ADD & BACK button many times to see the change.
